BM3
不锈钢材质，S 型结构，焊接密封，拉向或压向承载。防护等级 IP68
适用于吊钩秤、机改秤、料斗秤等各类电子称重设备。
技术指标
额定载荷 | t | 0.5/1 /2/2.5/3/4/5/6/7.5; I | ||
| 精度 | C3 | A5S | B10S | |
最大检定分度数 | nmax | 3000 | 5000 | 10000 |
最小检定分度值 | Vmin | Emax/10000 | Emax/15000 | Emax/10000 |
综合误差 | (%FS) | ≤ ±0.020 | ≤ ±0.018 | ≤ ±0.035 |
蠕变 | (%FS/30min) | ≤ ±0.016 | ≤ ±0.012 | ≤ ±0.030 |
温度对输出灵敏度的影响 | (%FS/10°C) | ≤ ±0.011 | ≤ ± 0.009 | ≤ ±0.030 |
温度对零点输出的影响 | (%FS/10°C) | ≤ ±0.015 | ≤ ±0.010 | ≤ ±0.030 |
输出灵敏度 | (mV/V) | 2.0 ±0.004 | ||
输入阻抗 | (Ω) | 350 ±3.5 | ||
输出阻抗 | (Ω) | 351 ±2.0 | ||
绝缘阻抗 | (MΩ) | 2 5000(50VDC) | ||
零点输出 | (%FS) | ≤ ±1.0 | ||
温度补偿范围 | (°C) | 一10 ~ +40 | ||
允许使用温度范围 | (°C) | -35 ~ +70 | ||
推荐激励电压 | (V) | 5 ~ 12(DC) | ||
最大激励电压 | (V) | 18(DC) | ||
安全过载范围 | (%FS) | 150 | ||
极限过载范围 | (%FS) | 300 | ||
0.5 | 1.0 | 2.0 〜2.5 | 3.0 | 4.0 | 5.0 | 6.0 | 7.5 | |
W | 32 (1.26) | 32 (1.26) | 32 (1.26) | 32 (1.26) | 36 (1.42) | 50 (1.97) | 50 (1.97) | 50 (1.97) |
H | M12 x1.75 | M12 x1.75 | M20 x1.5 | M20 x1.5 | M20 x1.5 | M24 x2 | M24 x2 | M24 x2 |
M | 25 (0.98) | 25 (0.98) | 25 (0.98) | 25 (0.98) | 25 (0.98) | 24 (0.94) | 24 (0.94) | 24 (0.94) |
