Sensitivity

(mV/V)

2.0 ±0.2

Accuracy

C3

C4

C5

Composition Error

(%FS)

≤±0.02

≤±0.015

≤±0.01

Creep

(%FS/30min)

≤±0.0167

≤±0.0125

≤±0.01

TC Span

(%FS/10°C)

≤±0.0175

≤±0.0131

≤±0.01

TCO

(%FS/10°C)

≤±0.02

≤±0.012

≤±0.009

Zero balance

(%FS)

≤±2

Temperature compensation range

(°C)

-10 ~ 40

Service Temp Range

(°C)

-35 ~ 65

Input Resistance

(Ω)

406 ±6

Output Resistance

(Ω)

350 ±3

Insulation Resistance

(MΩ)

≥5000 ( 50VDC )

Recommended excitation voltage

(V)

5 ~ 12(DC)

Maximum excitation

(V)

18(DC)

Safe Load Limit

(%FS)

120

Breaking Load Limit

(%FS)

150

Protection Class

IP65

Cable Specification

mm

Ф 5.0

Cable Length

m

2

Recommended Scale Size

mm

600x600

Recommended Installation Torque

N.m

20
